The multifunctional vacuum freeze dryer developed by Shandong Joyang Machinery Co., Ltd. is widely used in food, meat, pet food, vegetables, fruits, fruit powder, flowers, coffee, plant extracts, Chinese medicinal materials, Cordyceps sinensis, sea cucumber, biological products and chemical products freeze drying.
The product processed by the vacuum freeze drying equipment has the characteristics of no nutrient loss, maintaining the original color of the material, no deformation, excellent taste and mouth feel, storage resistance and not easy to deteriorate.
The vacuum freeze dryer can be connected to a computer for remote operation and can easily record lyophilized data. Equipped with large color touch screen and PLC control system, the operation process of the equipment can be monitored in real time.
The vacuum freeze dryer produced by our company has features of low energy consumption, simple and convenient operation, energy saving, environmental protection, the material is heated evenly. The value of the final product is highly improved.
Besides of the freeze dryer, we can provide all necessary solutions and machines for to preprocess the materials, and pack the product. Welcome to contact us!
Flow Chart of Universal Vacuum Freeze Dryer:
Product --- Preprocessing -- Loading & conveying --Freezing & forming -- Freeze storage -- Vacuum freeze drying -- Discharging -- Packaging -- Final product
Sample:
|
Model |
JY-DG5 |
JY-DG10 |
JY-DG20 |
JY-DG30 |
JY-DG60 |
JY-DG100 |
JY-DG120 |
|
Drying Size |
5 m2 |
10 m2 |
20 m2 |
30 m2 |
60 m2 |
100 m2 |
120 m2 |
|
Capacity |
75 kg |
150 kg |
300 kg |
450 kg |
800 kg |
1200 kg |
1400-1600 kg |
|
Capacity |
50 kg |
100 kg |
200 kg |
300 kg |
600 kg |
1000 kg |
1200 kg |
|
Equipment Size |
3.8×1.2×1.9 m |
5.8×1.7×2 m |
7.5×1.7×2 m |
9.0×1.7×2 m |
11.5x6.0x3.8 m |
20x5.0x3.8 |
20x6.0x3.8 |
|
Tray Quantity |
12 pcs |
24 pcs |
48 pcs |
72 pcs |
136 pcs |
224 pcs* 2 sets |
272 pcs * 2 sets |
|
Tray Size |
440×550 mm |
610×710 mm |
610×710 mm |
610×710 mm |
610×710 mm |
610×710 mm |
610×710 mm |
|
Tray height |
35 mm |
35 mm |
35 mm |
35 mm |
35 mm |
35 mm |
35 mm |
|
Power |
18 kw |
34 kw |
56 kw |
83 kw |
100 kw |
300 kw |
360 kw |
